TS83 Size 3-6 Overhead Door Closer with Backcheck

Product Overview

The Dorma TS83 Overhead Door Closer is designed for versatility and reliability, featuring an adjustable strength range of size 3-6. This makes it suitable for various door types and environments.

Key Features

• Weight and Width Capacity: Accommodates doors weighing up to 120kg and measuring a maximum width of 1400mm.
• Compliance and Testing: Fully tested to BS EN1154 standards and CE Marked, ensuring high-quality performance and safety.
• Functionality: Equipped with backcheck, adjustable closing speed, and adjustable latch action for enhanced control. For detailed information on these functions, please refer to our FAQs.

Product Specifications

• Fitting Type: Overhead
• Standards Compliance: Tested to BS EN1154
• Fire Testing: EN1634 - 120 Minutes (Timber), 240 Minutes (Steel)
• Applications: Compatible with Fig 1, Fig 61, and Fig 66
• Dimensions:
  • Height: 60mm
  • Width: 47mm
  • Length: 245mm
• Maximum Door Weight: 120kg
• Maximum Door Width: 1400mm
• Adjustable Strength: Size 3-6
• Adjustable Closing Speed: Yes
• Adjustable Latch Action: Yes
• Delayed Action: No
• Backcheck Feature: Yes
• Hold Open Functionality: No (For hold open, use part number: 22003001 - Dorma Hold Open Arm. Note: Not suitable for use on Fire Doors if hold open arm is fitted.)
