This Tesa 10 Bolt Key wind lock features a 20mm U-Rail faceplate and a 50mm or 60mm backset.
Manufacturer: Tesa
Case Height: 175mm
Length: 2028mm
Pin Bolts: 10
Faceplate: 20mm U-Rail
Distance between outer locking points: 1600mm
Copy/Genuine: Genuine
Cylinder Type: Euro
Handing: Not Handed
Spindle: Single 8mm
Packaging: Supplied in singles
Measuring Backset
To measure the backset, you need to determine the distance from the edge of the door to the center of the keyhole. This measurement is crucial for ensuring that the lock fits properly in your door.
Measuring Centres
The centres PZ measurement is taken from the center of the keyhole to the center of the handle hole. This ensures that both components align correctly for optimal functionality.
Understanding Key Wind Operation
The key wind operation refers to how the lock is engaged and disengaged using a key. In this case, turning the key will wind the internal mechanism to secure or release the locking bolts.
Packaging Information
The Tesa 10 Bolt Key wind lock is supplied in singles, making it easy to purchase just what you need for your project.
