Lever Operated Latch & Deadbolt Single Spindle Gearbox To Suit Mila

The YALE Doormaster Lever Operated Latch & Deadbolt Single Spindle Gearbox is designed specifically for Mila systems, providing a seamless solution for those looking to repair or refurbish existing door setups. With a 35mm backset, 92mm centres, and a 50mm case width, this gearbox is tailored to fit older Mila cases without the need for a complete replacement.

This cost-effective option allows for easy installation, but it's important to note that the fixing points are unthreaded, necessitating the use of self-tapping screws for secure fitting. Additionally, some older locks may feature an offset or cranked connector, which is crucial to check before proceeding with the installation. While replacement gearboxes now come with inline connectors, they remain compatible with older locks. However, users will need to modify the square hole in the drive gear into a slot for proper functionality.

Handing

Reversing the latch is straightforward: simply remove the screw on the side of the case, take out the latch, flip it to the opposite hand, and reattach the screw.

Operation

• Locking Method: Lift the lever to engage the locking mechanisms, then turn the cylinder one full turn to lock. To unlock, turn the key one full turn and push down on the lever.

Features

• Designed for Mila systems
• Single spindle configuration
• Centre gearbox only
• Includes both latch and deadbolt
• Compatible with euro profile lock cases

This gearbox not only enhances the functionality of your door system but also ensures that you can maintain the integrity of your existing locks with minimal hassle.
