Acoustic Hold Open Door Release Device

Product Information

Wedging open fire doors is dangerous. Dorgard is a wireless solution that legally holds open fire doors and enables them to close when the fire alarm sounds.

This acoustically activated fire door retainer keeps a fire door open legally and closes the door in the event of an alarm.

• Activated after hearing a general noise or continuous sound exceeding 65 decibels.
• The door releases 14 seconds after sound activation.

PLEASE NOTE: The Dorgard floor plates and door labels are no longer included when you purchase this item. Dorgard has stopped supplying the floor plates because they are rarely needed. If you require them, you can register your Dorgard after purchase at https://register.fireco.uk and enter the code that comes with your Dorgard. From there, you will be able to order the accessories.

Product Specification

• Overall height: 205mm
• Casing height: 150mm
• Width: 195mm
• Depth: 45mm
• Weight: 700g
• Power: 2 x 1.5v C-size batteries
• Max door size: Power size 7, max weight 160kg
• Suitable for FD30, FD60, and FD120 fire doors up to EN power size 7
• Built-in safety feature releases the closer if the general noise level exceeds 65 decibels.
• Automatic night-time release facility.
• Battery-operated wireless unit.
• Complies with BS EN 1155.
• Complies with BS 7273-4 Cat C.
• CE marked.
• Black supplied from stock, but other colors available by special order.

Activation: After hearing a continuous sound exceeding 65 decibels, the door is released 14 seconds after sound activation.
