Acoustic Hold Open Door Release Device

It is dangerous to wedge open fire doors. Dorgard is a wireless system which legally holds fire doors open and allows them to close when the fire alarm sounds.

This acoustically activated fire door retainer holds a fire door open in a legal position, and closes it when an alarm sounds.

• It’s triggered when it hears a general noise, or continuous sound, of 65 decibels or more.
• The door opens 14 seconds after the sound activation.

PLEASE NOTE: When you purchase this item, the Dorgard floor plates and door labels are no longer included. Floor plates are rarely required so Dorgard no longer supply them. If you need to, you can register your Dorgard after purchase at register.fireco.uk and enter the code that comes with your Dorgard. You can order the accessories from there.

Product Specification.

• Total height: 205 mm
• Height of houses: 150mm
• 195mm wide
• Depth: 45cm
• Weight: 700 g
• Power: 2 x 1.5v C cell batteries
• Maximum door size Power size 7 Maximum weight 160 kg
• Suitable for FD30, FD60 and FD120 fire doors up to EN power size 7
• Built-in safety feature releases closer if general noise level exceeds 65 decibels.
• Automatic release facility at nighttime.
• Wireless unit, battery powered.
• Compliant to BS EN 1155.
• BS 7273-4 Cat C compliant.
• CE-marked.
• Black supplied from stock . Other colours available by special order.

Sound activation: The door is released 14 seconds after hearing a continuous sound above 65 decibels.
