6345 2 Hooks Timber and Composite Repair Multipoint Door Lock

Introducing the ERA Lock, expertly crafted for remedial work on timber and composite doors. This robust lock features two high-security hooks, ensuring exceptional anti-separation resistance. With a 20mm faceplate and a 45mm backset, it is designed for durability and reliability.

Key Features

• High Security: Equipped with twin high-security hooks for enhanced protection.
• Versatile Operation: Supports lift lever or split spindle nightlatch operation.
• Easy Latch Reversal: Simply undo the screw in the latch to reverse it, making installation straightforward.
• Nightlatch Reversal: A small screw allows for easy adjustment of the nightlatch position.

Included Components

• 3-piece lock and keep set
• Fixing screws pack
• Set of packers for installation

Product Specifications

• Centres: 92mm
• Case Height: 221mm
• Case Depth: Backset + 18mm
• Overall Length: 1960mm
• Minimum Length: 1040mm
• Maximum Top Hook to Spindle: 816mm
• Minimum Top Hook to Spindle: 360mm
• Maximum Bottom Hook to Spindle: 871mm
• Minimum Bottom Hook to Spindle: 415mm

This ERA lock is the perfect solution for enhancing the security of your doors while ensuring ease of installation and operation.
